HES-3106-SE

6-Port Management Gigabit Ethernet CPE Switch

HES-3106-SE series provides a user-friendly but advanced IPv4/IPv6 management interface and abundant L2 switching functions.

The built-in iProbe monitoring toolset, including end-user client emulation and IPTV monitoring, to name a few, fulfills advanced network diagnostics and makes precise fault-identifying required less effort to be achieved, which also brings you extra assistance on preventative maintenance. RF model supports CATV RF receiver interface that provides the option of provisioning analog video service to create new subscriber base and revenue for service provides.

CTSystems
IPv4/IPv6 Dual Stack
Supports both IPv4 and IPv6, saving your costs when transitioning from IPv4 to a IPv6 network
CTSystems
Loop Detection
Automatically prevents the loop events from causing congestion in the network and keeps your service stable
CTSystems
Fast and Secured Installation
Manages and secures the fiber cable and fiber connector with a fiber cable tray, which is a perfect for green field installations
CTSystems
Power Down Trap
Lets the device send a last message to the NOC when power is shut off and saves costs on deploying human resource for trouble shooting
CTSystems
Dual Rate Fiber
Automatically senses and adjusts the fiber speed when changes are made in the network environment, providing a longer lifespan for the product
CTSystems
Flexible IPTV Deployment
Designed with rich functions in facilitating multimedia streaming and provides a stable IPTV service with high quality
CTSystems
DHCP Auto Provisioning
Automatically upgrades the firmware and configuration from DHCP server to save the maintenance cost
CTSystems
Dual Image
Prevents your device to die from firmware upgrade failures
CTSystems
iProbe
IPTV monitoring, end user device emulation and cable test that makes troubleshooting easy through Web GUI, CLI, SNMP & Schedule *Supports HES-3106/HES-3106-PLUS/HES-3106B only.
Model
Info
Version
Download File
HES-3106-SE
Manual (NMS)

V0.9

HES-3106-SE
Manual (NMS)

V0.9

ModelsFiber PortTP PortCATV RFPower Source
SpeedTypeConnectorDistancePortSpeedPortFiberCoaxial
HES-3106BW2A(SM-10)SE-DR100/1000MbpsWDMSC10km110/100/1000Mbps5External Power Adapter
HES-3106BW2A(SM-10)SE-DR-RF100/1000MbpsWDMSC10km110/100/1000Mbps511
HES-3106SFP-SE-DR100/1000MbpsSFP110/1000Mbps5
