FOS-3110

10-Port Managed Full Gigabit Ethernet Fiber Switch

FOS-3110 Enterprise switch is a Fiber Gigabit Ethernet100/1000Base-X and 10/100/1000Base-T switch with robust metal case.

The FOS-3110 enterprise switch can be easily managed by Web GUI, telnet CLI, and SNMP. To fulfill the requirement of mass deployment, the device also supports the auto provisioning mechanism to allow the network managers to manage the device automatically and dynamically to save the OPEX. With CTS unique power down trap feature, FOS-3110 is able to send out a SNMP trap message when unexpected power outage occurs.

CTSystems
Loop Detection
Automatically prevents the loop events from causing congestion in the network and keeps your service stable
CTSystems
DHCP Auto Provisioning
Automatically upgrades the firmware and configuration from DHCP server to save the maintenance cost
CTSystems
Dual Rate Fiber
Automatically senses and adjusts the fiber speed when changes are made in the network environment, providing a longer lifespan for the product
CTSystems
Power Down Trap
Lets the device send a last message to the NOC when power is shut off and saves costs on deploying human resource for trouble shooting
CTSystems
IPv4/IPv6 Dual Stack
Supports both IPv4 and IPv6, saving your costs when transitioning from IPv4 to a IPv6 network
CTSystems
Flexible IPTV Deployment
Designed with rich functions in facilitating multimedia streaming and provides a stable IPTV service with high quality
CTSystems
Dual Image
Prevents your device to die from firmware upgrade failures
CTSystems
Intelligent Diagnostics
Allow system operational monitoring in real-time, and instantly fault-identify SFF-8472-specification-compatible optical modules according to user-defined threshold parameters.
Model
Info
Version
Download File
FOS-3110
Manual

V1.1

CT System Downloads
FOS-3110
Manual (NMS)

V1.0

CT System Downloads
FOS-3110
Datasheet

A01

CT System Downloads
ModelsFiber PortsTP PortsSupport power source
SpeedTypePortsSpeedPorts
FOS-3110-1A100/1000MbpsSFP1010/100/100Mbps2Fixed 1 Internal AC
